StarTech.com   PCI Express 10Gb Ethernet Adapter

StarTech.com PCI Express 10Gb Ethernet Adapter

CCL Code: NET2703

Discontinued

StarTech.com PCI Express 10Gb Ethernet Adapter

PEX10GSFP4I

Key Features:

  • PCI Express Interface
  • 4 Network Ports
  • Speed: 10000Mbps
CCL Code: NET2703

Discontinued

Sorry, this product has been discontinued. We have found some similar products below.

Overview

This SFP+ server network card delivers reliable, high-performance network connectivity, by adding four open SFP+ slots to your server or high-powered workstation. It provides an easy and cost-effective way to upgrade to a 10 Gigabit fiber network using SFP+ modules of your choice and gives you the flexibility to use either multimode or single-mode fiber.

Add redundant connections in zero-downtime environments

With multiple available ports, you can avoid network downtime by adding fault-tolerant connections using two or more modules to provide high-bandwidth network links to your mission-critical servers or workstations.

Increase your network speed

This PCIe network card lets you take advantage of the increased speed and stability of a 10 Gigabit network, with data transfers of up to 10Gbps.

Add scalable network connections to your server or workstation

The network interface card is compatible with most 10GbE SFP+ transceivers. This gives you flexible and scalable configuration options, for connecting your computer directly to a fiber network at greater distances.

The card features four open SFP+ slots with support for interchangeable 10GBase SFP+ modules. This gives you the option to use the fiber transceiver modules that best suit your network needs based on distance and connector type. StarTech.com offers a wide variety of SFP+ transceiver modules to suit your network requirements. In addition, StarTech.com SFP+ cables provide a dependable solution for linking telecom and data communications equipment, such as routers and switches.

Enhance your network capabilities

The SFP+ server network card features the Intel® XL710 chipset, delivering the power, performance and enhanced capabilities you need for reliable connections to your server or computer. The Intel chip offers many advanced features including Intel® Virtualization Technology for Connectivity, PXE network boot support and up to 9K jumbo frame support.

The PEX10GSFP4I is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Main Features

  • Provide redundant network links to mission-critical systems
  • Add four 10GbE SFP+ slots to your server or workstation for fast, high-bandwidth connectivity, compatible with SR or LR transceivers
  • Compatible with multimode and single-mode fiber
  • Intel XL710 chipset with Intel Virtualization Technology for Connectivity
  • PXE network boot support
Specifications

Network

Network Speeds Supported 20000 Mbps
Data Link Protocol 2Gb Fibre Channel
Protocols Supported IEEE 802.3ad (Link Aggregation) • IEEE 802.3x (Flow Control Support) • IEEE 802.1Q (VLAN tagging)
Protocol Fibre Channel
Connectivity Technology Wired
Flow Control IEEE 802.3 2005

Interfaces/Ports

Number of Ports 4 port(s)
Port Connector SFP+
Network Card Bus PCI Express x8
Fibre Port 4 x SFP+ Slot

System Requirements

Operating Systems Supported Windows 7, 8, 8.1, 10 (64-bit Only) • Windows Server 2008 R2, 2012, 2012 R2, 2016 (64-bit Only) • Linux 2.6.24 to 4.11.x (64-bit Only)< LTS Versions only
Network Operating Systems Supported The maximum throughput of this card is limited by the businterface. PCI Express Gen 1.0 max throughput is 2Gbps perlane. PCI Express Gen 2.0 max throughput is 4Gbps perlane. PCI Express Gen 3.0 max throughput is 8Gbps perlane. The available bandwidth (64Gbps) is shared equallybetween the four ports.

Compliance

Compliant Standards RoHS

Environmental

Operating Temperature 5 to 50 °C
Operating Humidity 20 to 80 %

Warranty

Warranty 2-year warranty

Physical

Form Factor PCI Card
Colour Black
Status Indicators 4 x Link/Activity (green)
Pack Quantity 1
In The Box Network card • Quick-start guide
Width 1.5 cm
Depth 13.9 cm
Height 10.0 cm
Weight 0.122 kg

Key Features

LAN Port Connector SFP
LAN Port Speed 10000 Mbps
Number of LAN Ports 4 port(s)
Interface Type PCI Express
Main Colour Black
Drive Interface Type PCIe 3.0 x4 NVMe

Item Details

Manufacturer StarTech.com
Manufacturer Code PEX10GSFP4I
EAN 0065030867740
UPC 065030867740
Condition New
Warranty

Warranty Information

Warranty 2-year warranty

Manufacturer Information

Manufacturer StarTech.com
Manufacturer Code PEX10GSFP4I
